Sulfur Pellets, Difficult Material Conveyors

This WB300 bucket conveyor feeding sulfur prills to a domed Silo was installed at a refinery in the Middle East. The total sulfur conveyor height is around 100 feet (30 meters). The conveyor has been in continuous operation since 2005. This NERAK bucket conveyor was specially designed to “hug” the domed roof for easy maintenance access and esthetics.

Another project realized for a sulfur production facility is shown on the attached pdf to the right.
Here we also transport sulfur prills coming from a priller and transport them into a silo.

All internal parts are designed to withstand the brutal properties of sulfur. The material selection of the internal parts ensures a long life of all components. Ranging from fiber-reinforced nylon buckets to rubber chains and flaps made from SBR and EPDM and rods made from stainless steel.

NERAK designs every bucket conveyor to application and ensures that every material conveyed is matched with the most suitable material for every component in the conveyor. We at NERAK understand that you will rely on our equipment for years to come. We will not let you down! This WB300 bucket conveyor was delivered in 2001 and has been operating since. It is 89 feet (27 meters) high.







At the heart of every NERAK conveyor are the quiet, stretch-free Rubber Block Chains
